FUENTE DE PODER GAMEMAX GM SEMI-MODULAR 600W

$57.900

Sin existencias

Compare
SKU: 00848 Categoría: marca:
Compartir

Descripción

PSU Specifications

AC INPUT: 100-240 VAC 8-4A 50-60Hz
DC
Output
Max
+3.3V +5V +12V1 +12V2 -12V +5VSB
18A 18A 20A 20A 0.5A 2.5A
600W

Connectors

GameMax 20+4 Pin Main Connectors:

1

GameMax 4+4 Pin 12V Connectors:

1

GameMax SATA Connectors:

6

GameMax 4-Pin Molex Connectors:

3

GameMax 6+2 Pin PCI-e Connectors:

2

Detailed Specifications

Dimensions: 160mm x 85mm x 150mm (W x H x D)
Input Voltage: 100-240 VAC
Input Current: 6-10A
Input Frequency Range: 50-60Hz
PFC: Active PFC (>.99)
Power Good Signal: 100-500 ms
Hold Up Time: >17ms
Efficiency: > 81% (85% max)
MTBF: > 100,000 Hours
Protection: OVP / UVP/ OTP / OCP / OLP / OPP / SCP
Power: 600W
Operation Temperature: 0-40C
Safety: CE / FCC / CB
Cooling: 140mm Ultra Silent Fan
Noise: <25dBa
80 Plus Certified: Yes – 80 Plus Bronze

General Specifications

Manufacturer Part Number: GM-600
EAN Number: 6931858730020
Has Mains Plug: No
Colour: Black
What’s In The Box: Power Supply
Screws
Manual
5 x Output Cables
2 x Cable Ties
Unit (Product) Dimensions (mm): 160mm x 85mm x 150mm (W x H x D)
Packaging Dimensions (mm): 335mm x 242mm x 122mm (W x H x D)
Net Weight (KGs): 1.8 KGs
Gross Weight (KGs): 2.5 KGs
